W76
|
Type |
Solid Fuel Room Heater |
Type of Combustion |
Non-catalytic |
Fuel Type |
Dry Cordwood (15% moisture) |
Main Material |
Cast Iron |
Firebox Isolation |
Vermiculite |
Flue Exit |
6” (150 mm) Back to top connector |
Recommended Heating Area |
450 to 2,000 ft.2 (42 to 185 m2) |
Nominal Firebox Volume |
1.55 ft.3 (0.044 m3) |
Maximum Burn Time 1 |
14 hours |
Maximum Heat Output (dry cordwood) 2 |
57,700 BTU/h (16.91 kW) |
Overall Heat Output Rate (min. to max.) 2 3 |
13,784 BTU/h to 57,684 BTU/h
(4.04 kW to 16.91 kW) |
Average Overall Efficiency 3 |
71% (HHV) 4 76% (LHV) 5 |
Optimum Efficiency 5 |
78% |
Average Particulate Emissions Rate 7 |
1.81 g/h (EPA/CSA B415.1-10) |
Average CO5 |
120 g/h |
